X3U Entry Level IP Phone

Fanvil X3U – Entry‑Level Gigabit IP Phone

A cost‑effective, feature‑rich SIP phone ideal for small to medium offices and home use.

• 2.8″ color LCD (320 × 240)

• 3 LED line keys, plus 4 soft-keys & navigation dial

• Around 37 physical buttons total including dial pad & function keys

• Supports 6 SIP accounts

• 3-way local conferencing and hotspot mode

• Standard telephony: hold, transfer, forward, intercom, voicemail, call park/pickup, DND, auto-answer, hot-desking, blacklist/whitelist, speed-dial

Audio Quality

• HD audio: G.722, Opus; also G.711, G.726, G.729A/B, iLBC, optional G.723.1

• Full-duplex speakerphone with AEC, AGC, VAD, CNG, noise reduction

• Dual Gigabit Ethernet (10/100/1000 Mbps) with PC pass-through

• Supports IPv4/IPv6, VLAN, QoS, 802.1x, OpenVPN, LLDP, TR-069

• Dual PoE, optional 5 V/0.6 A AC adapter

Headset & Expansion

• RJ9 headset port, supports EHS adapters for Plantronics/Jabra

• USB support for recording (via flash drive)

Phonebook, Logs & Provisioning

• Local phonebook: up to 1,000 entries; remote LDAP/XML support

• Call logs: incoming/outgoing/missed (600 entries)

• Auto-provisioning via FTP/TFTP/HTTP(S)/DHCP/SIP PnP/TR‑069; web management portal

• Power: PoE (IEEE 802.3af) or optional 5 V/0.6 A adapter

• Power consumption: 0.9–2.95 W active, ~0.9–1.65 W idle

• Device dimensions: ~169 × 177–186 × 174–183 mm (multi‑angle desktop stand)

• Temperature tolerance: 0–45 °C; humidity 10–95%

Ideal For:

Entry-level VoIP deployments, soft switching, small office/home office use—offering HD audio, gigabit networking, full VoIP feature set, and PoE support in a compact design.
